NoteAction
Shown in figure Location of oil
plugs on page 122.
Open the oil plug, filling.3
Where to find type of oil and
total amount is detailed in Type
and amount of oil in gearboxes
on page 121.
Refill the gearbox with clean lubricating oil.
The correct oil level is detailed in section Inspecting
the oil level in axis-1 gearbox on page 102.
4
Tightening torque: 25 Nm.Refit the oil plug, filling.5
Product manual - IRB 460 125
3HAC039842-001 Revision: P
© Copyright 2012-2018 ABB. All rights reserved.
3 Maintenance
3.4.2 Changing oil, axis-1 gearbox
Continued
