Page #385 background imageLoading...
Page #385 background image
Article no.QtyDescription
-1Guide pins M10x140
(Used with one of the M10x150 guide pins
when replacing the axis 2 and 3 gear-
boxes)
3HAC025333-0052Lifting eye M12
3HAC040381-0012Adapter
(used with lifting eye M12)
-2Shackle, lifting capacity 1,000 kg
(Used with lifting eye M12)
-2Lifting eye bolt, M20
-2Shackle, lifting capacity 2,000 kg
(Used with lifting eye bolt M20)
-1Crank
3HAC040028-0011Press tool, premounting outer race bear-
ing
The tool consists of:
• 3HAC040028-002 Pressing tool for
bearing
• 3HAC040028-003 Pressing tool for
bearing
• 3HAC040021-004 Pressing tool
• 3HAC040021-005 Hollow cylinder
RCH 123
• 3HAC040022-004 Threaded bar
M16
3HAC040029-0011Press tool, replacing shaft tilthouse
The tool consists of:
• 3HAC040029-002 Pressing tool
bearing
• 3HAC040029-003 Pressing tool
bearing
• 3HAC040021-004 Pressing tool
• 3HAC040021-005 Hollow cylinder
RCH 123
• 3HAC040022-004 Threaded bar
M16 length 450 mm (removal). For
refitting length 350 mm.
3HAC040035-0011Auxiliary shaft
Used together with press tool
3HAC040029-001 (only when removing).
3HAC040025-0011KM7 socket
3HAC040027-0011Adapter
Continues on next page
Product manual - IRB 460 385
3HAC039842-001 Revision: P
© Copyright 2012-2018 ABB. All rights reserved.
7 Reference information
7.7 Special tools
Continued
