ABB IRB 460 Series - Page 386

Article no.QtyDescription
3HAC040026-0011Press tool, upper arm
The tool is also used as Pull tool. Differ-
ence: Press bushing is used instead of
support bushing.
The tool consists of:
• 3HAC040026-003 Press bushing
• 3HAC040026-002 Pressing tool
upper arm
• 3HAC040021-004 Thread washer
• 3HAC040021-005 Hollow cylinder
RCH 123
• 3HAC040022-004 Threaded bar
M16 length 350 mm.
3HAC040026-0011Pull tool, upper arm
The tool is also used as Press tool. Differ-
ence: Support bushing is used instead of
Press bushing.
The tool consists of:
• 3HAC040026-004 Support bush-
ing
• 3HAC040026-002 Pressing tool
upper arm
• 3HAC040021-004 Thread washer
• 3HAC040021-005 Hollow cylinder
RCH 123
• 3HAC040022-004 Threaded bar
M16 length 350 mm.
3HAC040023-0011KM12 socket
3HAC040022-0021Auxiliary shaft
3HAC040030-0011Press tool link, bearing outer races
3HAC040031-0011Lower part of pressing tool
3HAC040022-0011Press tool, link
The tool consists of:
• 3HAC040022-002 Pressing tool
• 3HAC040022-003 Pressing tool
• 3HAC040021-004 Pressing tool
• 3HAC040021-005 Hollow cylinder
RCH 123
• 3HAC040022-004 Threaded bar
M16 length 350 mm.
3HAC040024-0011KM8 socket
3HAC040021-0011Mounting/Demounting tool
(Parallel rod)
The tool consists of:
• 3HAC040021-004 Pressing tool
• 3HAC040021-002 Pressing tool
• 3HAC040021-003 Pressing tool
• 3HAC040021-005 Hollow cylinder
RCH 123
• 3HAC040021-006 Threaded bar
M16 length 530 mm.
-1Shims thickness 8 mm
Continues on next page
