Illustration, fitting on turning disk
The illustration below shows the mounting holes available for fitting equipment on
the turning disk.
xx1000001042
(A)
(B)
Y
X
xx1800001402
Tool flange in bottom view-
Locating holeA
Tool coordinate systemB
Continues on next page
Product manual - IRB 460 77
3HAC039842-001 Revision: P
© Copyright 2012-2018 ABB. All rights reserved.
2 Installation and commissioning
2.3.7 Fitting equipment on robot
Continued
