NoteArticle numberSpare part
The maintenance kit contains:
• End cover
• Radial sealing with dust
lip, (2 pcs)
• O-ring
• Spherical roller bearing
• Washer
3HAC087168-001Maintenance set, link ear
Required tools and equipment
NoteArticle numberEquipment
Used to secure lower arm.-Lock screw, M16x120
Used to unload or restore a balan-
cing device.
User instructions are enclosed
with the tool.
3HAC074411-001Hydraulic press equipment, balan-
cing device
Used for removing and fitting
shaft and bearings.
User instructions are enclosed
with the tool.
3HAC028920-001Dismantle and mounting tool
To be used with the press and
puller tools.
See technical specifications in the
user instructions for the press
equipment.
3HAC11731-1Hydraulic cylinder
To be used with the press and
puller tools.
See technical specifications in the
user instructions for the press
equipment.
3HAC13086-1Hydraulic pump 80 MPa
SA-10-8-NA1-Lifting shackle
Lifting instruction 3HAC15880-2
enclosed.
3HAC15556-1Lifting accessory (chain)
Content is defined in section
Standard toolkit on page 628.
-Standard toolkit
Required service parts
NoteArticle numberConsumable
Located at the front link ear of the
balancing device.
Replace if damaged.
3HAC4836-26Protection plug
Tribol GR 100-0 PD3HAA1001-294Grease
Loctite 2400 (or equivalent Loctite
243)
-Locking liquid
Loctite 2400 (or equivalent Loctite
243)
-Locking liquid
Continues on next page
Product manual - IRB 6710 205
3HAC085695-001 Revision: A
© Copyright 2023 ABB. All rights reserved.
5 Repair
5.3.2 Replacing spherical roller bearing, balancing device link ear
Continued
