ABB IRB 6710 - Page 490

NoteAction
xx2200001737
Disconnect the signal cable connector by
pulling it out.
4
xx2200001738
Remove the cable bracket by removing the
screws.
5
Remove the motor cables from the motor.6
Removing the axis-2 motor
NoteAction
Before removing the motor, make sure that
the gearbox is completely drained.
1
