101510 Rev. AG Page 3–
3.30.1 Instructions
1) If configured, the optional equipment unit should contain an installed power
supply. The Optional Equipment Enclosure Installation
should be
installed using instructions shown previously in this chapter.
2) Remove the necessary plugs from the side of the enclosure to install the rigid
conduit.
3) Pipe the conduit and associated AC wiring into the enclosure.
Please review the Grounding the NGC section in, System
Description, before making power connections.
4) Using wiring instructions in Figure 3-65, make the field connections from the 115
VAC hot and neutral or the two hot wires for 230 VAC.
5) Pipe the conduit and associated DC wiring from the NGC into the power supply
enclosure. See Table 2–4
for wire sizes.
6) Remove the J1 connector from the NGC termination panel. Using the wiring
instructions in Figure 3-65
, make field connections from the power supply wire
as shown to J1 connector (+) pin and connect the ground wire to J1 connector (-)
pin. Do not re-insert the J1 connector to the termination board.
7) Proceed to the Battery Pack Installation instructions later in this chapter.
8) Go to DC Power Installation later in this chapter.
