Page 3–16
2101510 Rev. AG
Figure 3-15 ENC82S–Channel Tubing Installation
Figure 3-16 ENC82S–Pipe Mount Split Brackets
Spring Nut
Screw, Lock Washer &
Washer
Existing Channel
Tubing
Screw, Lock Washer
& Washer
Spring Nut
