Figure 2-21 ENC82L
Environmental
Enclosure
with Catalytic Heater
Figure 2-22: ENC82S Environmental Enclosure with Electric Heater
CATALYTIC HEATER OPTION
BOTTLE RACK OPTION
POWER SWITCH
PWR/COMM
OUTLET BOX
THERMOSTAT
INSULATED
ENCLOSURE WALL
CALIBRATION BLEND
CALIBRATION BLEND BOTTLE
CYLINDER: M009
FITTINGS: CGA180
HEATER KIT:
VARITHERM 120
VAC, 400 WATT
THERMOSTAT
INSULATED
ENCLOSURE
WALL
BOTTLE RACK OPTION
