ABB NGC8206 - Feed-Through Assembly; Figure 2-6 NGC8206 Enclosure Right Side; Figure 2-7 NGC8206 Enclosure Underside

2
101510 Rev. AG Page 2–
9
Figure 2-6 NGC8206 Enclosure Right Side
Figure 2-7 NGC8206 Enclosure Underside
2.3.4 Feed-through Assembly
Independent sample streams are connected to the NGC directly to the feed-
through assembly (see Figure 2-8
), or through an optionally installed sample
conditioning module. The feed-through assembly also serves as the connection
