ABB NGC8206 - 115;230 VAC to 12 VDC Explosion-Proof Power Supply Installation; Figure 3-65 115;230 VAC UPS Power Supply Option

Page 3–62
2101510 Rev. AG
Figure 3-65 115/230 VAC UPS Power Supply Option
3.31 115/230 VAC to 12 VDC Explosion-Proof Power Supply Installation
Before beginning, review the procedure and the materials required for installation.
BATTERYOUTPUT
INPUT
OUTPUT
Power Supply
Quint
-PS-100-
240AC/
24DC/10
UPS
Quint-DC-
UPS
24DC/20
External AC Power Source (Supplied by customer)
Fuse Block
Spares
TB5, Spare 1Amp max
TB4, Spare 1Amp max
TB3, Spare 1Amp max
TB2, NGC 5Amp max
TB1, Batt 10Amp max
1
2 2
1
2
2
1
2
To NGC
(Supplied by
customer)
Bus Bar
(-)
(+)
J1
1 4
24 VOLT
UPS
(-) SEE NOTE 2
Dual 50AH Battery
Kit
P/N 2104054-001
24V UPS Charger
P/N 2104006-003
6870 Enclosure
P1
(+)
(-)
(+)
(-)
(+) RED (+) RED
(-) BLK (-) BLK
(+)
1 2 3 4
Cable
P/N 2018359-008
