15 DIMENSIONS AND LAYOUTS
15.1 Dimensions and Weights
The following tables show the dimensions and weights of different types of enclosures.
Enclosure
Size
Dimensions
H x W x D
mm
Enclosure Type
Weight
kg
Shared Enclosures
B
2154 x 1209 x 804
Inverters, Utility
Disconnect
and Coupling Transformer
150 kVA
785
300 kVA
1120
Inverters and Utility
Disconnect
450 kVA
685
600 kVA
770
750 kVA
850
Dedicated Enclosures
A
2154 x 809 x 804
Inverter Enclosure
Master
690
Slave
633
Ultracapacitor Energy
Storage
One string
450
Two
strings
690
Battery Energy Storage
One string
2043
Empty
639
C
2154 x 1209 x 804
Utility Disconnect
2200 A
900
4200 A
980
Fail-Safe Bypass
2200 A
700
4200 A
790
Coupling Transformer
Typically, 2 kg/kVA
Contact ABB for actual weights.
D
2154 x 809 x 1204
Coupling Transformer
E
2154 x 1609 x 1204
Coupling Transformer
F
2154 x 1209 x 1204
Coupling Transformer
Note: Allow ±10% tolerance for all weights shown in tables above.
