7 USER INTERFACE
7.1 Graphic Display Module
The primary user interface for configuration of the PCS100 UPS-I is via the Graphic Display Module (GDM) which is
mounted in the door of the master inverter enclosure. It allows local control of the PCS100 UPS-I and shows the
system status and provides access to the operating parameters and event history.
The GDM interface consists of several pages; each page has a navigation & control panel and the status bar at the
top. The Navigation & Control Panel and the Status Bar are displayed at all times.
The navigation panel consists of buttons allowing page selection and the control panel consists of a Start (I) /
Stop (O) / Reset button allowing local control of the product.
The status bar displays the current product status and any warning or fault condition that may be present.
Table 7-1 describes general features of GDM, and Figure 7-1 displays Status page of GDM.
Table 7-1: PCS100 UPS-I GDM features
The GDM screen consists of following parts:
1. Navigation & Control Panel
2. Status Bar
3. Page (selectable)
