PCS100 UPS-I User Manual 93
10.3.9 Menu 800 Status-Currents
800 Status-Currents
This menu contains current measurements. Will be updated when entering the menu.
Parameter:
810 Utility L1
Function:
Displays the Utility RMS current in Line 1
Units
Amperes
Note:
Current detected by CTs fitted in the utility disconnect enclosure.
Parameter:
811 Utility L2
Function:
Displays the Utility RMS current in Line 2
Units
Amperes
Note:
Current detected by CTs fitted in the utility disconnect enclosure.
Parameter:
812 Utility L3
Function:
Displays the Utility RMS current in Line 3
Units
Amperes
Note:
Current detected by CTs fitted in the utility disconnect enclosure.
Parameter:
813 Coupling Transformer L1
Function:
Displays the coupling transformer RMS current in Line 1
Units
Amperes
Note:
Current detected by CTs fitted in the coupling transformer primary (delta) winding.
Parameter:
814 Coupling Transformer L2
Function:
Displays the coupling transformer RMS current in Line 2
Units
Amperes
Note:
Current detected by CTs fitted in the coupling transformer primary (delta) winding.
Parameter:
815 Coupling Transformer L3
Function:
Displays the coupling transformer RMS current in Line 3
Units
Amperes
Note:
Current detected by CTs fitted in the coupling transformer primary (delta) winding.
Parameter:
816 Coupling Transformer N
Function:
Displays the calculated RMS current in the coupling transformer neutral
Units
Amperes
Note:
Calculated from the sum of the instantaneous currents measured by the CTs in the delta
windings of the coupling transformer.
Table 10-10: Menu 800 Status-Currents
