86 PCS100 UPS-I User Manual
10.3.5 Menu 400 GDM Services
400 GDM Services
This menu contains the status of various GDM services.
Parameter:
411 Webserver Status
Function:
Displays the status of the webserver.
Range:
Should display “Running” This parameter is not displayed if the webserver service is not
available.
Parameter:
421 Vcanserver Status
Function:
Displays the status of the Vcanserver.
Range:
Should display “Running”
Note:
Vcanserver is the software module interfacing the CAN bus used by the PCS100 UPS-I
master controller to the webserver in the GDM.
Parameter:
431 Modbus Status
Function:
Displays the status of the Modbus TCP Service
Range:
Should display “Running”
Note:
After a software upgrade the PCS100 UPS-I needs to be rebooted twice to initialize the
Modbus
Parameter:
441 NTP Status
Function:
Displays the status of the NTP (Network Time Protocol) client service.
Range:
“Running clock updated” if the NTP server connection is successful.
“Invalid Server Name” if no NTP server IP address has been set.
“Server connection failed” if no response from the NTP server was received.
Note:
Wait at least 30 seconds after setting the NTP server IP address Parameter 442 NTP
Server before refreshing menu 400 GDM Services.
The NTP Status field will be updated when entering the menu.
Parameter:
442 NTP Server
Function:
IP address of an NTP (Network Time Protocol) server.
Range:
Any valid IPv4 formatted IP address.
Setting up:
Enter the IP address of the NTP server. Wait for at least 30 seconds before refreshing the
‘400 GDM Services’ menu to check 441 NTP Status.
Parameter:
443 NTP Time Zone
Function:
Specifies the local time zone offset from UTC.
Range:
+/- 13
Units
hours
Table 10-6: Menu 400 GDM Services parameters
