28 PCS100 UPS-I User Manual
4.7 Energy Storage - Batteries
System DC Nominal Voltage
672V DC (56 x 12V DC)
Discharging Voltage Range
780 V DC to 554 V DC
Overload Capacity
100%
Rated Power
240 kW per string
Autonomy Period
30 s @ 240 kW
For more information refer to ABB Document
2UCD120000E018
Operating Temperature
15 °C to 25 °C (recommended)
Design Life
10 years at 25 °C
Cycle Life
> 800 (full load 30 s discharge)
Recharge Time
< 30 min
4.8 Event Recording
Measurement Method
Line to Line
Sample Time
125 µs
Resolution of time stamp in
event log
10 ms
Measurement Type
Half-cycle RMS according to IEC 61000-4-30
4.9 Environmental
Operating temperature range
0° C to 40° C (32° F to 104° F)
Operating altitude
< 1000 m without derating
Capacity derating with
altitude
1% every 100 m
above 1000 m
2000 m maximum
Humidity
< 95%, non-condensing
Pollution degree rating
2
Noise
< 75dBA @ 2 m
Storage temperature range
-30° C to 50° C (-22° F to 122° F)
Packaging
Must be kept dry at all times including
transportation and storage. Protect against contact
with rain or other water or liquids and do not store
in damp or humid conditions.
