10.3.12 Menu GDM B00 Network Settings
GDM B00 Network Settings
This menu contains parameters to setup the GDM Ethernet port.
Parameter:
B11 Dynamic IP DHCP
Function:
Configures the Dynamic Host Configuration Protocol (DHCP).
This is displayed on the Product Page.
Range:
True = Dynamic, False = Static
Access:
Operator
Setting Up:
The network may be configured using either static or dynamic configuration methods.
The static method is the simplest for a direct connection to a PC. The IP address for the
GDM is manually configured via parameter B12 below. The PC IP address in Windows may
also need adjusting. The Dynamic method is when the computer's IP address is assigned
automatically, in which case parameter B12 and B13 does not need to be entered.
Dynamic IP addresses are most frequently assigned on LANs and broadband networks by
a Dynamic Host Configuration Protocol (DHCP) server. On any but the simplest network
the network administrator’s assistance will probably be required. Parameter B15 Apply
Settings must be set to TRUE to save this setting.
Parameter:
B12 Static IP address
Function:
Configures the GDM Static IP address
Range:
###.###.###.### (where ### = 1 to 255)
Access:
Operator
Setting Up:
Parameter B15 Apply Settings must be set to TRUE to save this setting.
See section 12.2 for further setting up instructions.
Parameter:
B13 Static IP mask
Function:
Configures the Static IP mask
Range:
###.###.###.### (where ### = 1 to 255)
Access:
Operator
Setting Up:
Example: 255.255.254.0
Parameter B15 Apply Settings must be set to TRUE to save this setting.
See section Error! Reference source not found. for further setting up instructions.
Parameter:
B14 Static IP gateway
Function:
Configures the Static IP gateway
Access:
Operator
Setting Up:
Parameter B15 Apply Settings must be set to TRUE to save this setting.
See section Error! Reference source not found. for further setting up instructions.
Parameter:
B15 Apply Settings
Function:
Applies the network settings B11, B12, B13 and B14.
Select True to update the configuration.
Range:
True / False
Access:
Operator.
Setting Up:
To view the actual settings currently used by the PCS100 UPS-I see the Product Page in
section 7.1.5.
See section 12.2 for further setting up instructions.
Table 10-13: Menu GDM B00 Network Settings
