PCS100 UPS-I User Manual 89
Parameter:
536 Transient Filter
Function:
Specifies the time-constant of the transient detection filter
Access:
Tech
Range:
0 to 50
Units:
ms
Factory
Setting:
1.186
Setting up:
Refer to document 2UCD120000E014
Parameter:
540 Auto Start
Function:
Selects the PCS100 UPS-I automatic start up method after a power up
Access:
Tech
Range:
Name
Description
No
PCS100 UPS-I never automatically starts
Mem
PCS100 UPS-I remembers the start status at power down and applies the
same status after power up
Always
PCS100 UPS-I always automatically starts
Factory
Setting:
Mem
Note:
The remote start/stop terminals can override these settings
Parameter:
541 Start Command
Function:
Selects how a GDM start command and a start command via the Remote terminals on the
front of the master module work together. (A stop command will always have priority)
Access:
Tech
Range:
Name
Description
Local has Priority
Local control refers to the GDM. A GDM operator can override an active
Remote start signal by pressing the GDM stop button. This causes the
PCS100 UPS-I to trip (fault code 106). The GDM reset button will cause
the system to start if a Remote start signal is still present.
Remote has
Priority
The Remote start input is level sensitive. When a Remote start signal is
active in this mode, the stop button is removed from the GDM display
so a GDM operator cannot override an active Remote start command.
Edge Sensitive
In this mode the Remote start input is edge sensitive. The PCS100 UPS-
I will start when the start input transitions from open to closed. The
GDM start button can also start the PCS100 UPS-I.
Factory
Setting:
Local has Priority
Note:
See section Error! Reference source not found. for a description of the remote inputs.
Table 10-7: Menu 500 UPS Settings parameters
