PCS100 UPS-I User Manual 91
Parameter:
622 Discharge Min DC
Function:
Sets the DC voltage that will end the 620 Discharge – UD closed test.
Range:
0 to 1000
Units:
Volts
Factory
Setting:
605 Volts
Access:
Factory
Note:
Because the inverter currents become distorted while using the discharge test at lower
voltages, a limit is placed on how low the test should discharge the energy storage.
Parameter:
625 Force FSB Closed
Function:
Forces the Fail Safe Bypass closed
Range:
True / False
Factory
Setting:
False
Access:
Tech
Note:
Only for use with systems that do not include maintenance bypass.
Parameter:
630 Generate Event
Function:
Generates a protection event (warning/fault/info)
Range:
0 to 32767
Factory
Setting:
0
Access:
Tech
Note:
This should only be used as a part of the commissioning process. The PCS100 UPS-I
should be offline and in bypass. Generating a fault event will cause the PCS100 UPS-I to
go offline. The status bar will display the triggered event, the event log will log the event
(event type ‘Force’), and the status will be available via MODBUS.
Warnings will be active for 10 seconds. Faults will require resetting using the GDM or
digital inputs.
To generate a system event, enter the event number.
To generate an event for a module, multiply the module number by 1000 then add the
event number. For example, to generate a ‘VCAN error’ (code 68) on module 3, enter a
value of 3068 for this parameter.
Module faults will result in a reduced capacity warning on the status bar. The respective
module will flash ‘E0’ and the OK LED will flash.
Table 10-8: Menu 600 Tests
