2.3.4.3 LD0.VMMXU1 Three-phase voltage limit supervision (1)
Table 25: LD0.VMMXU1 Three-phase voltage limit supervision (1)
IEC 61850 name SA name Description Values
LD0.VMMXU1
.HiAlm.stVal HIGH_ALARM High alarm 1=Alarm
.HiWrn.stVal HIGH_WARN High warning 1=Warning
.LoAlm.stVal LOW_ALARM Low alarm 1=Alarm
.LoWrn.stVal LOW_WARN Low warning 1=Warning
2.3.4.4 LD0.VMMXU2 Three-phase voltage limit supervision (2)
Table 26: LD0.VMMXU2 Three-phase voltage limit supervision (2)
IEC 61850 name SA name Description Values
LD0.VMMXU2
.HiAlm.stVal HIGH_ALARM High alarm 1=Alarm
.HiWrn.stVal HIGH_WARN High warning 1=Warning
.LoAlm.stVal LOW_ALARM Low alarm 1=Alarm
.LoWrn.stVal LOW_WARN Low warning 1=Warning
2.3.5 Power quality functions
2.3.5.1 LD0.CMHAI1 Current total demand distortion (1)
Table 27: LD0.CMHAI1 Current total demand distortion (1)
IEC 61850 name
SA name Description Values
LD0.CMHAI1
.Alm.stVal ALARM Distortion alarm 10=Alarm
2.3.5.2 LD0.VMHAI1 Voltage total harmonic distortion (1)
Table 28: LD0.VMHAI1 Voltage total harmonic distortion (1)
IEC 61850 name
SA name Description Values
LD0.VMHAI1
.Alm.stVal - Distortion alarm 1=Alarm
