2.5.2 Switchgear functions
2.5.2.1 CTRL.CBCSWI1 Circuit breaker, 4-pole (2 bit) position value (1)
Table 121: CTRL.CBCSWI1 Circuit breaker, 4-pole (2 bit) position value (1)
IEC 61850 name SA name Description Values S Arg 1,2,3,4
CTRL.CBCSWI1
.Pos.stVal POSITION
Intermediate=0; Off=1; On=2;
Bad=3 0…3 R 0,3,0,3
2.5.2.2 CTRL.DCXSWI1 Disconnector control (1)
Table 122: CTRL.DCXSWI1 Disconnector control (1)
IEC 61850 name SA name Description Values S Arg 1,2,3,4
CTRL.DCXSWI1
.Pos.stVal POSITION
Intermediate=0; Off=1; On=2;
Bad=3 0…3 R 0,3,0,3
2.5.2.3 CTRL.DCXSWI2 Disconnector control (2)
Table 123: CTRL.DCXSWI2 Disconnector control (2)
IEC 61850 name
SA name Description Values S Arg 1,2,3,4
CTRL.DCXSWI2
.Pos.stVal POSITION
Intermediate=0; Off=1; On=2;
Bad=3 0…3 R 0,3,0,3
2.5.2.4 CTRL.DCXSWI3 Disconnector control (3)
Table 124: CTRL.DCXSWI3 Disconnector control (3)
IEC 61850 name
SA name Description Values S Arg 1,2,3,4
CTRL.DCXSWI3
.Pos.stVal POSITION
Intermediate=0; Off=1; On=2;
Bad=3 0…3 R 0,3,0,3
2.5.2.5 CTRL.DCXSWI4 Disconnector control (4)
Table 125: CTRL.DCXSWI4 Disconnector control (4)
IEC 61850 name
SA name Description Values S Arg 1,2,3,4
CTRL.DCXSWI4
.Pos.stVal POSITION
Intermediate=0; Off=1; On=2;
Bad=3 0…3 R 0,3,0,3
