2.3.8 Generic functions
2.3.8.1 LD0.MAPGAPC1 Multipurpose analog protection function (1)
Table 75: LD0.MAPGAPC1 Multipurpose analog protection function (1)
IEC 61850 name SA name Description Values
LD0.MAPGAPC1
.Op.general OPERATE Stage operate 1 = Operate
.Str.general START Stage start 1 = Start
2.3.8.2 LD0.MAPGAPC2 Multipurpose analog protection function (2)
Table 76: LD0.MAPGAPC2 Multipurpose analog protection function (2)
IEC 61850 name SA name Description Values
LD0.MAPGAPC2
.Op.general OPERATE Stage operate 1 = Operate
.Str.general START Stage start 1 = Start
2.3.8.3 LD0.MAPGAPC3 Multipurpose analog protection function (3)
Table 77: LD0.MAPGAPC3 Multipurpose analog protection function (3)
IEC 61850 name
SA name Description Values
LD0.MAPGAPC3
.Op.general OPERATE Stage operate 1 = Operate
.Str.general START Stage start 1 = Start
2.3.8.4 LD0.MAPGAPC4 Multipurpose analog protection function (4)
Table 78: LD0.MAPGAPC4 Multipurpose analog protection function (4)
IEC 61850 name
SA name Description Values
LD0.MAPGAPC4
.Op.general OPERATE Stage operate 1 = Operate
.Str.general START Stage start 1 = Start
2.3.8.5 LD0.MAPGAPC5 Multipurpose analog protection function (5)
Table 79: LD0.MAPGAPC5 Multipurpose analog protection function (5)
IEC 61850 name
SA name Description Values
LD0.MAPGAPC5
.Op.general OPERATE Stage operate 1 = Operate
.Str.general START Stage start 1 = Start
