2.5.3.3 LD0.RESCMMXU1 Residual current (1)
Table 140: LD0.RESCMMXU1 Residual current (1)
IEC 61850 name SA name Description Values S Arg 1,2,3,4
LD0.RESCMMXU1
.A.res.instCVal.mag I0_INST Residual current 0.00..40.0 [xIn] R 0,40,0,4000
2.5.3.4 LD0.VMMXU1 Voltage measurement (1)
Table 141: LD0.VMMXU1 Voltage measurement (1)
IEC 61850 name SA name Description Values S Arg 1,2,3,4
LD0.VMMXU1.PhV Phase-to-ground voltage
.phsA.cVal.mag U_DB_A -phsA magnitude
0.00…4.00
[xUn] R 0,4,0,400
.phsB.cVal.mag U_DB_B -phsB magnitude
0.00…4.00
[xUn] R 0,4,0,400
.phsC.cVal.mag U_DB_C -phsC magnitude
0.00…4.00
[xUn] R 0,4,0,400
LD0.VMMXU1.PPV Phase-to-phase voltage
.phsAB.cVal.mag U_DB_AB -phsAB magnitude
0.00…4.00
[xUn] R 0,4,0,400
.phsBC.cVal.mag U_DB_BC -phsBC magnitude
0.00…4.00
[xUn] R 0,4,0,400
.phsCA.cVal.mag U_DB_CA -phsCA magnitude
0.00…4.00
[xUn] R 0,4,0,400
2.5.3.5 LD0.VMMXU2 Voltage measurement (2)
Table 142: LD0.VMMXU2 Voltage measurement (2)
IEC 61850 name
SA name Description Values S Arg 1,2,3,4
LD0.VMMXU2.PhV Phase-to-ground voltage
.phsA.cVal.mag U_DB_A -phsA magnitude
0.00…4.00
[xUn] R 0,4,0,400
.phsB.cVal.mag U_DB_B -phsB magnitude
0.00…4.00
[xUn] R 0,4,0,400
.phsC.cVal.mag U_DB_C -phsC magnitude
0.00…4.00
[xUn] R 0,4,0,400
LD0.VMMXU2.PPV Phase-to-phase voltage
.phsAB.cVal.mag U_DB_AB -phsAB magnitude
0.00…4.00
[xUn] R 0,4,0,400
.phsBC.cVal.mag U_DB_BC -phsBC magnitude
0.00…4.00
[xUn] R 0,4,0,400
.phsCA.cVal.mag U_DB_CA -phsCA magnitude
0.00…4.00
[xUn] R 0,4,0,400
