2.3.5.3 LD0.PHQVVR1 Voltage variation signals (1)
Table 29: LD0.PHQVVR1 Voltage variation signals (1)
IEC 61850 name SA name Description Values
LD0.PH1QVVR1
.VarStrGen.stVal - Variation event detected 1=Detected
.VarEnd.stVal - Variation event ended 1=Ended
.SwlOp.stVal - Swell event detected 1=Detected
.DipOp.stVal - Dip event detected 1=Detected
.IntrOp.stVal - Interruption event detected 1=Detected
2.3.5.4 LD0.VSQVUB1 Voltage unbalance detection (1)
Table 30: LD0.VSQVUB1 Voltage unbalance detection (1)
IEC 61850 name SA name Description Values
LD0.VSQVUB1
.VarStr.stVal Event start 1=Start
.HiPctVUnb.stVal Unbalance exceeds limit 1=Exceeds
2.3.6 Protection functions
2.3.6.1 LD0.PHLPTOC1 Phase overcurrent protection, low stage (1)
Table 31: LD0.PHLPTOC1 Phase overcurrent protection, low stage (1)
IEC 61850 name
SA name Description Values
LD0.PHLPTOC1
.Op.general OPERATE Stage operate 1=Operate
.Str.general START Stage start 1=Start
2.3.6.2 LD0.PHHPTOC1 Phase overcurrent protection, high stage (1)
Table 32: LD0.PHHPTOC1 Phase overcurrent protection, high stage (1)
IEC 61850 name
SA name Description Values
LD0.PHHPTOC1
.Op.general OPERATE Stage operate 1=Operate
.Str.general START Stage start 1=Start
Section 2 1MRS757807 B
DNP3 data mappings
26 Remote Monitoring and Control REC615
Point List Manual
