ABB Relion REC615 - Physical and Raw I;O Data; LD0.XGGIO100 Physical I;O; LD0.XGGIO110 Physical I;O

IEC 61850 name SA name Description Values
.SPCS14.stVal - Output 14 state 0/1=Off/On
.SPCS15.stVal - Output 15 state 0/1=Off/On
.SPCS16.stVal - Output 16 state 0/1=Off/On
2.3.9 Physical and raw I/O data
2.3.9.1 LD0.XGGIO100 Physical I/O
Table 91: LD0.XGGIO100 Physical I/O
IEC 61850 name SA name Description Values
LD0.XGGIO100
.SPCSO1.stVal - X100-Output 1 1/0=ON/OFF
.SPCSO2.stVal - X100-Output 2 1/0=ON/OFF
.SPCSO3.stVal - X100-Output 3 1/0=ON/OFF
.SPCSO4.stVal - X100-Output 4 1/0=ON/OFF
.SPCSO5.stVal - X100-Output 5 1/0=ON/OFF
.SPCSO6.stVal - X100-Output 6 1/0=ON/OFF
2.3.9.2 LD0.XGGIO110 Physical I/O
Table 92: LD0.XGGIO110 Physical I/O
IEC 61850 name
SA name Description Values
LD0.XGGIO110
.Ind1.stVal - X110-Input 1 1/0=ON/OFF
.Ind2.stVal - X110-Input 2 1/0=ON/OFF
.Ind3.stVal - X110-Input 3 1/0=ON/OFF
.Ind4.stVal - X110-Input 4 1/0=ON/OFF
.Ind5.stVal - X110-Input 5 1/0=ON/OFF
.Ind6.stVal - X110-Input 6 1/0=ON/OFF
.Ind7.stVal - X110-Input 7 1/0=ON/OFF
.Ind8.stVal - X110-Input 8 1/0=ON/OFF
.SPCSO1.stVal - X110-Output 1 1/0=ON/OFF
.SPCSO2.stVal - X110-Output 2 1/0=ON/OFF
.SPCSO3.stVal - X110-Output 3 1/0=ON/OFF
.SPCSO4.stVal - X110-Output 4 1/0=ON/OFF
Section 2 1MRS757807 B
DNP3 data mappings
42 Remote Monitoring and Control REC615
Point List Manual
