2.3.8.6 LD0.MAPGAPC6 Multipurpose analog protection function (6)
Table 80: LD0.MAPGAPC6 Multipurpose analog protection function (6)
IEC 61850 name SA name Description Values
LD0.MAPGAPC6
.Op.general OPERATE Stage operate 1 = Operate
.Str.general START Stage start 1 = Start
2.3.8.7 LD0.MVGAPC1 Multipurpose binary inputs (1)
Table 81: LD0.MVGAPC1 Multipurpose binary inputs (1)
IEC 61850 name SA name Description Values
LD0.MVGAPC1
.Q1.stVal - Input 1 signal 0/1=Off/On
.Q2.stVal - Input 2 signal 0/1=Off/On
.Q3.stVal - Input 3 signal 0/1=Off/On
.Q4.stVal - Input 4 signal 0/1=Off/On
.Q5.stVal - Input 5 signal 0/1=Off/On
.Q6.stVal - Input 6 signal 0/1=Off/On
.Q7.stVal - Input 7 signal 0/1=Off/On
.Q8.stVal - Input 8 signal 0/1=Off/On
2.3.8.8 LD0.MVGAPC2 Multipurpose binary inputs (2)
Table 82: LD0.MVGAPC2 Multipurpose binary inputs (2)
IEC 61850 name
SA name Description Values
LD0.MVGAPC2
.Q1.stVal - Input 1 signal 0/1=Off/On
.Q2.stVal - Input 2 signal 0/1=Off/On
.Q3.stVal - Input 3 signal 0/1=Off/On
.Q4.stVal - Input 4 signal 0/1=Off/On
.Q5.stVal - Input 5 signal 0/1=Off/On
.Q6.stVal - Input 6 signal 0/1=Off/On
.Q7.stVal - Input 7 signal 0/1=Off/On
.Q8.stVal - Input 8 signal 0/1=Off/On
