ABB Relion REC615 - LD0.VSMSQI1 Sequence of Voltage Measurement (1); LD0.VSMSQI2 Sequence of Voltage Measurement (2); LD0.FMMXU1 Frequency Measurement (1); LD0.HAEFMHAI1 Current Harmonics (1)

2.5.3.6 LD0.VSMSQI1 Sequence of voltage measurement (1)
Table 143: LD0.VSMSQI1 Sequence of voltage measurement (1)
IEC 61850 name SA name Description Values S Arg 1,2,3,4
LD0.VSMSQI1 Sequence of voltages
.SeqV.c1.cVal.mag I1_DB -Positive magnitude
0.00…4.00
[xUn] R 0,4,0,400
.SeqV.c2.cVal.mag I2_DB -Negative magnitude
0.00…4.00
[xUn] R 0,4,0,400
.SeqV.c3.cVal.mag I3_DB -Zero magnitude
0.00…4.00
[xUn] R 0,4,0,400
2.5.3.7 LD0.VSMSQI2 Sequence of voltage measurement (2)
Table 144: LD0.VSMSQI2 Sequence of voltage measurement (2)
IEC 61850 name SA name Description Values S Arg 1,2,3,4
LD0.VSMSQI2 Sequence of voltages
.SeqV.c1.cVal.mag I1_DB -Positive magnitude
0.00…4.00
[xUn] R 0,4,0,400
.SeqV.c2.cVal.mag I2_DB -Negative magnitude
0.00…4.00
[xUn] R 0,4,0,400
.SeqV.c3.cVal.mag I3_DB -Zero magnitude
0.00…4.00
[xUn] R 0,4,0,400
2.5.3.8 LD0.FMMXU1 Frequency measurement (1)
Table 145: LD0.FMMXU1 Frequency measurement (1)
IEC 61850 name
SA name Description Values S Arg 1,2,3,4
LD0.FMMXU1
.Hz.mag - Frequency value 35…75 [Hz] R 35,75,3500,7500
2.5.3.9 LD0.HAEFMHAI1 Current harmonics (1)
Table 146: LD0.HAEFMHAI1 Current harmonics (1)
IEC 61850 name
SA name Description Values S Arg 1,2,3,4
LD0.HAEFMHAI
.HRmsA.res.cVal.mag - Current harmonics 0…250 [A] R 0,250,0,250
1MRS757807 B Section 2
DNP3 data mappings
Remote Monitoring and Control REC615 57
Point List Manual
