2.4.5 Protection-related functions
2.4.5.1 LD0.DARREC1 Autoreclosing reset signals (1)
Table 110: LD0.DARREC1 Autoreclosing reset signals (1)
IEC 61850 name SA name Description Type
LD0.DARREC1
.RsCnt.Oper.ctlVal - AR reset all counters On
.RsRec.Oper.ctlVal - AR reset On
2.4.6 Generic functions
2.4.6.1 LD0.SRGAPC1 Multipurpose binary output flip-flop resets (1)
Table 111: LD0.SRGAPC1 Multipurpose binary output flip-flop resets (1)
IEC 61850 name SA name Description Type
LD0.SRGAPC1
.Rs1.Oper.ctlVal - Reset flip-flop 1 On
.Rs2.Oper.ctlVal - Reset flip-flop 2 On
.Rs3.Oper.ctlVal - Reset flip-flop 3 On
.Rs4.Oper.ctlVal - Reset flip-flop 4 On
.Rs5.Oper.ctlVal - Reset flip-flop 5 On
.Rs6.Oper.ctlVal - Reset flip-flop 6 On
.Rs7.Oper.ctlVal - Reset flip-flop 7 On
.Rs8.Oper.ctlVal - Reset flip-flop 8 On
2.4.6.2 LD0.SRGAPC2 Multipurpose binary output flip-flop resets (2)
Table 112: LD0.SRGAPC2 Multipurpose binary output flip-flop resets (2)
IEC 61850 name
SA name Description Type
LD0.SRGAPC2
.Rs1.Oper.ctlVal - Reset flip-flop 1 On
.Rs2.Oper.ctlVal - Reset flip-flop 2 On
.Rs3.Oper.ctlVal - Reset flip-flop 3 On
.Rs4.Oper.ctlVal - Reset flip-flop 4 On
.Rs5.Oper.ctlVal - Reset flip-flop 5 On
.Rs6.Oper.ctlVal - Reset flip-flop 6 On
.Rs7.Oper.ctlVal - Reset flip-flop 7 On
.Rs8.Oper.ctlVal - Reset flip-flop 8 On
