ScreenMaster RVG200
Paperless recorder 7 Configuration
OI/RVG200-EN 91
ACJC Type Note. This parameter is displayed only if Type has been set to
Thermocouple.
Select the automatic cold junction compensation required:
Per Module
Per Channel
External
–
–
–
the recorder automatically detects an automatic cold
junction device on another channel on the same
module.
an automatic cold junction device must be fitted to the
channel.
the automatic cold junction will be read from the
configured analog signal.
Electrical range low
Electrical range high
Note. These parameters are displayed only if Type has been set to
millivolts, milliamps, Volts or Resistance.
Set the required electrical range.
The range of the electrical input signal is determined by the input type –
see Table 7.2:
Input Standard inputs
type mV V mA
Minimum –150 –10 0 0
Maximum 150 25 50 10000
Table 7.2 Limits of electrical ranges
