TB82 TRANSMITTER
SPECIAL FEATURE
N - 12
SPECIAL FEATURE
The following section details unique special feature functions for the
TB82.
Sensor Data
This procedure describes how to view sensor data.
Use the arrow keys to adjust output shown on the
meter to 20 mA.
Key Display Comments
ENTER
ADJUST TO 20 mA
THEN HIT ENTER
ENTER
ID TAGNAME
READY
Key Display Comments
Select SENSOR DATA.
View slope and offset of the process.
Valid slope values are 40% to 150%. Valid offset val-
ues are -1,000 to +1,000 mV.
View slope and offset of the temperature.
Valid range for slope is 0.2 to 1.5. Valid range for off-
set is -40° to 40°C.
SPECIAL
FEATURE
FIX/CANCEL OUTPUT
→ SENSOR DATA
HART SP. FEATURE
ENTER
PROCESS
SLOPE : nn.nnnn
OFFSET: nn.nnnn
ENTER
TEMPERATURE
SLOPE : nn.nnnn
OFFSET: nn.nnnn
ENTER
ID TAGNAME
READY
