AS800 PRESSURE TRANSMITTER
CALIBRATION
P - 10
Temperature Calibration
Apply zero value to the transmitter.
ZERO TRIM is complete.
Key Display Comments
ENTER
APPLY 0 INPUT
TO SENSOR
THEN HIT ENTER
ENTER
ID TAGNAME
READY
Key Display Comments
This operation will cause a change in output not cor-
responding to the input. Be sure the control loop is in
manual.
Select YES.
Select TEMP. CAL.
If digitally configured, the D-TO-A ADJUST selection
will not appear.
Enter TEMPERATURE value,
.
CALI-
BRATE
OUTPUT WILL BE
AFFECTED! PROCEED?
NO
→ YES
ENTER
INPUT A/D CAL
D-TO-A ADJUST
ZERO TRIM
→ TEMP. CAL
ENTER
ENTER SENSOR
TEMPERATURE
ENTER
