APPENDIX P - AS800 PRESSURE TRANSMITTER
INTRODUCTION
This appendix covers the configuration and calibration functions of
the AS800 Pressure Transmitter.
Refer to OPERATING PROCEDURES in Section 4 for information on
the following functions:
NOTE: To change calibration or configuration parameters of a smart
field device that is connected to an IMFBS01 module, the device
must be taken off-line. This is done at the INFI 90 OPEN console.
CREATE/MODIFY CONFIGURATION
A configuration can be created off-line, without a connected field
device. Refer to Figure P-1 for an overview of the configuration
function. The following table details the configuration process.
The STT04 does not suppport configuration of the AS800 transfer
function or controller function.
• Send configurations. • Select configurations.
• Get configurations. • Erase configurations.
• View configurations. • Operational functions.
Figure P-1. Configuration Flowchart (AS800)
To Next Page
