OPERATING PROCEDURES
ERASE CONFIGURATION
4 - 10
ERASE CONFIGURATION
Use this function to erase a configuration from the STT04 terminal
memory.
NOTE: This procedure is identical for all device types.
This display appears when configuring HART trans-
mitters only. Two digits can be entered for the day,
month and year.
Configuration ID tag name just configured will be in
the upper left corner if the configuration was saved.
This becomes the working configuration.
Key Display Comments
ENTER
DATE:
DAY: nn
MONTH: nn
YEAR: nn
ENTER
ID TAGNAME
READY
Key Display Comments
Select ERASE.
Displays the stored configurations. Use the scroll
keys to select a stored configuration to view. The ID
tag name that is bracketed indicates it is selected for
deletion.
NOTE: To more quickly scroll through configurations
(three at a time) press the left arrow key to scroll
down or the right arrow key to scroll up.
To erase the selected configuration, use the down
arrow key to move the pointer to YES, then press
.
NOTE: To return to the READY screen without eras-
ing a configuration, press .
CONFIG
CONFIGURATION
NEW
MODIFY
→ ERASE
ENTER
STT04 CONFIGURATION
1. FT101
2. FT103
3. LT 106
ENTER
ERASE
ID TAGNAME
→ NO
YES
ENTER
CLEAR
