OPERATING PROCEDURES
GET CONFIGURATION
4 - 9
Damping value is displayed to the nearest hundredth
of a second.
Lower and upper range values are displayed.
Indicator points to the configured initialization mode.
Indicator points to the configured fail mode.
Secondary upper and lower range values are
displayed to the nearest hundredth.
Only applies if interfacing a PTS, PTH, EQS or EBTH
transmitter. The upper and lower range temperature
alarm values are shown as configured.
This display appears when configuring HART trans-
mitters only. A message of up to 32 characters can
be entered.
This display appears when configuring HART trans-
mitters only. A descriptor of up to 16 characters can
be entered.
Key Display Comments
ENTER
DAMPING
(0 - 32 SEC)
6.00 SEC
ENTER
LOWER RANGE VAL.
nn.nn UNITS
UPPER RANGE VAL.
nn.nn UNITS
ENTER
INITIALIZE MODE:
→ LOW
HIGH
ENTER
FAIL MODE:
→ LOW
HIGH
LAST
ENTER
SECONDARY L. R.
nn.nn UNITS
SECONDARY U. R.
nn.nn UNITS
ENTER
LOWER TEMP ALARM
-50.00°C
UPPER TEMP ALARM
120.00°C
ENTER
MESSAGE:
←PREVIOUS NEXT→
ENTER
DESCRIPTOR:
←PREVIOUS NEXT→
To Next Page
