600T & 600T EN PRESSURE TRANSMITTER
CALIBRATION
Q - 20
FACTORY TRIM
Use this option if factory setting is to be used for calibration.
Key Display Comments
This operation will cause a change in output not cor-
responding to the input. Be sure the control loop is in
manual.
Select YES.
Select SENSOR TRIM, or select calibration option
with down-arrow key and refer to the appropriate
section. Press
when done.
Select FACTORY TRIM.
CALI-
BRATE
ENTER
OUTPUT WILL BE
AFFECTED! PROCEED?
NO
→ YES
ENTER
→ SENSOR TRIM
D-TO-A ADJUST
PV BIAS
SET OUTPUT %
ENTER
ENTER
FULL TRIM
ZERO TRIM
→ FACTORY TRIM
STATIC TRIM
ENTER
ID TAGNAME
READY
