SMART POSITIONER
CREATE/MODIFY CONFIGURATION
A - 4
Move the indicator to proper selection.
Refer to the Smart Positioner instruction for an expla-
nation of terms.
The input can be damped with a value of 1 to 5 sec-
onds. A value of 0 will disable this parameter.
Set the deviation alarm in % of deviation from the set
point.
Sets the low pressure alarm for the supply pressure.
Sets the percent of span that the digital output will be
activated.
Sets the minimum input value (in % of span) that the
control element will go to 0%.
Select a DO3 action with the arrow keys. Reference
Positioner instruction for details.
NOTE: Scroll with the up and down arrow keys to
view other selections.
Select YES using arrow keys.
Key Display Comments
ENTER
INPUT SIGNAL:
→ NORMAL ACT
REVERSE ACT
ENTER
DAMPING:
(0 - 5 sec)
n SECS
ENTER
DEVIATION ALARM
n.n%
ENTER
LOW PRES ALARM
nn.nn UNITS
HIGH PRES ALARM
nn.nn UNITS
ENTER
LOW LIMIT SIGNAL
nn.nn %
HIGH LIMIT SIGNAL
nn.nn %
ENTER
LOW FLOW SHUTOFF
n.n %
ENTER
DO3 ACTION:
→ LO PRESS
DEVIATION ALARM
VALVE STUCK ALARM
ENTER
STORE THIS
CONFIGURATION?
NO
→ YES
To Next Page
