3-50 Machine Maintenance Procedures
LCD Bezel Removal 0
Prerequisite:
LCD (Liquid Crystal Display) Module Removal
1. Locate the LCD Bezel (A) on the LCD module (Figure 3-50)
Figure 3-50. LCD Module Overview with Bezel
2. Remove the two (2) mylar covers and two (2) screws (C) from module. (Figure 3-51)
Figure 3-51. LCD Module Bezel Screws
A
B
B
CC
SG_JE50_HR.book Page 50 Thursday, December 23, 2010 3:47 PM
