Acer Aspire 5750, 5750G User Manual

1-32 Hardware Specifications and Configurations
LED 15.6”
LCD Inverter (not available with this model)
Item Specification
Vendor/Model name AUO/B156XW02 V6 (HW:0A)
AUO/B156XW02 V2 (HW:4A)
Samsung/LTN156AT02-A11
LG/LP156WH2-TLEA
CMO/N156B6-L0B
CPT/ CLAA156WB11A
Screen Diagonal (mm) 394.91 mm
Active Area (mm) 344.23 mm x 193.54 mm
Display resolution (pixels) 1366 x 3(RGB) x 768
Pixel Pitch (mm) 0.252mm × 0.252 mm
Typical White Luminance (cd/m
2
)
also called Brightness
200 cd/m2
Contrast Ratio 400 min / 500 type
Response Time (Optical Rise
Time/Fall Time) msec
8 ms / 16 ms
Typical Power Consumption
(watt)
5.15 W
Weight (without inverter) 460 max
Physical Size (mm) 360 mm x 210mm x 5.5 max
Electrical Interface 1 channel LVDS
Viewing Angle (degree)
Horizontal (Right) CR = 10 (Left)
Vertical (Upper) CR = 10 (Lower)
40 (Right) / 40 (Left) / 10 (Upper) / 30 (Lower) min.
Item Specification
Vendor & Model name
Brightness conditions
Input voltage (v)
Input current (mA)
Output voltage (V, RMS)
Output current (mA, RMS)
Output voltage frequency
(KHz)

Acer Aspire 5750, 5750G Specifications

General

RAM	Up to 8 GB DDR3
Wireless	802.11b/g/n Wi-Fi
LAN	Gigabit Ethernet
Processor	Intel Core i3, i5, or i7
Display	15.6" HD (1366x768) LED-backlit
Graphics	Intel HD Graphics 3000 or NVIDIA GeForce GT 520M/540M
Storage	Up to 750 GB HDD
Optical Drive	DVD Super Multi DL
Operating System	Windows 7 Home Premium
Battery	6-cell Li-ion battery
Weight	2.6 kg (5.7 lbs)
Chipset	Intel HM65 Express
Webcam	1.3 MP
Card Reader	Multi-in-1 card reader
Ports	3 x USB 2.0, HDMI, VGA, Ethernet, Headphone, Microphone
