ACUTRONIC fabian User Manual

7 Alarms 52
fabian Therapy evolution | SW V5.1.x
Ref: 121003.EN / Date: 26Jan2021
#
Alarm Text
Alarm Type
Cause
Solution
Main
Priority
Sub
Priority
checksum
monitor PIC
System failure
System error
Contact your local
ACUTRONIC Medical
Systems Distributor
I
2
Low physical
memory -
please reboot!
System failure
System error
Contact your local
ACUTRONIC Medical
Systems Distributor
I
2
Air supply
pressure
System alarms
Air supply pressure
too low.
Ensure pressure
above 2 bar.
I
2
Oxygen supply
pressure
System alarms
Oxygen supply
pressure too low.
Ensure pressure
above 2 bar.
I
2
Safety relay
defect
System failure
Safety relay defective.
Contact your local
ACUTRONIC Medical
Systems Distributor
I
2
Tube
Occlusion
System alarms
• Expiration tube
blocked/kinked
• Inspiration tube
blocked/kinked
• Excessive
deviation
between
inspiration and
expiration
pressure sensor.
NOTE : Coughing and
crying can cause a
false tube occlusion
alarm.
• Check ventilation
tubes.
• Check pressure
sensor connection
(proximal).
• Contact your local
ACUTRONIC
Medical Systems
Distributor
I
2
Voltage
monitoring
System failure
System error
Contact your local
ACUTRONIC Medical
Systems Distributor
I
2
Battery defect
Electrical
power
No power or too less
power from battery.
• Change battery,
• Check fuse.
I
2
Charge
battery
(<15min)
Electrical
power
• Ventilator is not
connected to
mains supply.
• Remaining
battery time <15
min.
• Switch to mains
supply.
The device
continues in
battery mode
without
interruption.
• Alarm may be
silenced with
Alarm Silence
button.
I
2

ACUTRONIC fabian Specifications

General

Type	Neonatal and Pediatric Ventilator
Manufacturer	ACUTRONIC Medical Systems AG
Model	fabian
Respiratory Rate	1 - 150 bpm
FiO2 Range	21 - 100%
HFOV Frequency	5 - 20 Hz
Power Supply	100-240 V AC, 50/60 Hz
Modes of Ventilation	SIMV, CPAP, HFOV
Tidal Volume Range	2 to 300 ml
PEEP/CPAP	0-20 cmH2O
Inspiratory Time	0.1 to 3 seconds
Flow Rate	2 - 30 L/min
Flow Sensor	Integrated
Pressure Limit	10-80 cmH2O
