ACUTRONIC fabian User Manual

53 7 Alarms
fabian Therapy evolution | SW V5.1.x
Ref: 121003.EN / Date: 26Jan2021
#
Alarm Text
Alarm Type
Cause
Solution
Main
Priority
Sub
Priority
Depleted
battery!
Electrical
power
Remaining battery
time <1 min.
Ventilation can no
longer continue on
battery power
Immediately switch to
mains supply or
access alternative
ventilation
I
2
check Blender
System alarms
Proportional mixer or
control defective
Contact your local
ACUTRONIC Medical
Systems Distributor
I
2
Patient
disconnected
Disconnection ∕
Tubes blocked
Leak or
disconnection.
• Check tubing
system for leaks.
• Check setting of
Pinsp.
I
3
flow sensor
calibration
required
Sensor alarms
Flow sensor is not
calibrated
Calibrate flow sensor
I
4
O
2
value out
of range
Sensor alarms
O
2
level is out of
range
Calibrate O
2
sensor
and / or Contact your
local ACUTRONIC
Medical Systems
Distributor.
I
4
Clean flow
sensor
Sensor alarms
Water or secretion in
flow sensor
Clean/replace flow
sensor.
I
4
Flow sensor
defect
Sensor alarms
Damaged heating
wires inside flow
sensor.
Replace flow sensor.
I
4
Flow sensor
not connected
Sensor alarms
• Flow sensor not
connected.
• Defective sensor
cable.
Check flow sensor
and sensor cable
connection.
I
4
O
2
sensor
calibration
failed
Sensor alarms
Error occurred during
calibration.
Repeat calibration.
I
4
Oxygen sensor
defect
Sensor alarms
O
2
sensor defective.
Replace O
2
sensor.
I
4
Oxygen sensor
used up
Sensor alarms
O
2
sensor worn.
Replace O
2
sensor as
quickly as possible.
Calibration still
available.
I
4

ACUTRONIC fabian Specifications

General

Type	Neonatal and Pediatric Ventilator
Manufacturer	ACUTRONIC Medical Systems AG
Model	fabian
Respiratory Rate	1 - 150 bpm
FiO2 Range	21 - 100%
HFOV Frequency	5 - 20 Hz
Power Supply	100-240 V AC, 50/60 Hz
Modes of Ventilation	SIMV, CPAP, HFOV
Tidal Volume Range	2 to 300 ml
PEEP/CPAP	0-20 cmH2O
Inspiratory Time	0.1 to 3 seconds
Flow Rate	2 - 30 L/min
Flow Sensor	Integrated
Pressure Limit	10-80 cmH2O
