ACUTRONIC fabian User Manual

7 Alarms 54
fabian Therapy evolution | SW V5.1.x
Ref: 121003.EN / Date: 26Jan2021
#
Alarm Text
Alarm Type
Cause
Solution
Main
Priority
Sub
Priority
O
2
value out
of range
Sensor alarms
O
2
sensor or mixer
defective.
• Repeat
Calibration and/or
Replace O
2
sensor.
• Disconnect the
device from AC
power and
contact your local
Acutronic Medical
Systems
Distributor.
I
4
SpO
2
module
disconnected
Sensor alarms
SpO
2
module is not
connected
Connect SpO
2
module
I
5
SpO
2
sensor
failure
Sensor alarms
SpO
2
sensor is faulty
Replace sensor or
Contact your local
ACUTRONIC Medical
Systems Distributor.
I
5
check SpO
2
sensor
Sensor alarms
SPO
2
sensor is off
patient or
malfunctioning
Connect SpO
2
sensor
to patient
I
5
Apnea alarm
Patient alarms
No spontaneous
patient breathing
detected.
• Check patient,
• Switch to
controlled
ventilation.
I
6
low SIQ
Patient alarms
SPO
2
sensor has low
SIQe (Signal Quality)
Check SpO
2
sensor for
correct contact with
patient or replace
sensor
I
7
FiO
2
at max
Patient alarms
FiO
2
has reached
maximum setting
Adjust settings
I
7
Lower
minimum FiO
2
Patient alarms
Lower minimum FIO
2
than set for PRICO
Adjust settings
I
7
High Pressure
Patient alarms
Pressure rise in tubing
system; mechanical
inspiration was
reduced to relieve the
system.
NOTE : High PIP alarm
should be set to at
least +2mbar above
Pmax.
• Check patient,
• Check tubing
system.
• Replace patient
system.
I
7

ACUTRONIC fabian Specifications

General

Type	Neonatal and Pediatric Ventilator
Manufacturer	ACUTRONIC Medical Systems AG
Model	fabian
Respiratory Rate	1 - 150 bpm
FiO2 Range	21 - 100%
HFOV Frequency	5 - 20 Hz
Power Supply	100-240 V AC, 50/60 Hz
Modes of Ventilation	SIMV, CPAP, HFOV
Tidal Volume Range	2 to 300 ml
PEEP/CPAP	0-20 cmH2O
Inspiratory Time	0.1 to 3 seconds
Flow Rate	2 - 30 L/min
Flow Sensor	Integrated
Pressure Limit	10-80 cmH2O
