87
Note
Letter, numeral, symbol
Notes of the pressure gauge
Table 5- 1 Task mode analog pressure gauge information
3. Task setting features
Select the task in the task list to enter the instrument parameter interface, click the start icon to enter
the execution information interface, and input the calibration information of the pressure gauge .
Item
Effective value
Description
Set points
The effective value of the
set point pressure
depends on the pressure
range of the gauge; upto
17 calibration points can
be set
Set the calibration points for the task, and the
calibrator will automatically set the default
calibration point based on the range of the
calibrated instrument and the number of the
calibration points. Any point can be manually
selected to be changed to a different point. The set
point needs to be within the range of the pressure
gauge. Change the number of the calibration points
through the arrow key on the right side of the
screen or by clicking the number of the calibration
points.
Cycle number
1, 2, 3
Select the number of cycles
Stroke
Round trip and one way
Select the calibration task stroke mode
