88
The number of
readings
Integer of 1 ~ 6
Input the number of readings to be taken when the
calibrator reaches the set point
Reading interval
Integer of (1 ~ 600)
seconds
Interval time between two readings
Dwell time
Integer of (1 ~ 600)
seconds
The waiting time before readings are taken and the
calibrator advances to the next set point.
Input format
Value, the number of
scales
1. Value: Digital display of pressure value
2. The number of scales: The pressure value is
displayed by counting the number of scales to
facilitate the reading and comparison with the value
indicated by the analog pressure reading. The
calibrated reading = standard value + deviation
number of scales X minimum scale division
Tapping
Enable, disable
When enabled the value of the analog pressure
gauge needs to be input twice for each calibration
point, and then the calibrator will shift to the next
calibration point to continue the task.
Table 5- 2 Task setting of analog pressure gauge
