96
Figure 5- 2 Calibration of the pressure sensor
Item
Effective value
Description
Name
Letter, numeral, symbol
Name of the pressure sensor
Serial number
Letter, numeral, symbol
Serial number of the pressure sensor
Model
Letter, numeral, symbol
Model of the pressure sensor
Pressure type
Gauge pressure, absolute
pressure, differential
pressure
Pressure type of the pressure sensor
Input
Depends on the pressure
sensor
Pressure range of the pressure sensor
