97
Output
(4~20)mA, (0~20)mA,
(1~5)V, (0~10)V,
(0~100)mV, (0~200)mV,
and custom
Electric signal output range of current/voltage and
pressure sensors
Accuracy
0.01%, 0.02%, 0.05%,
0.1%, 0.2%, 0.5%, 1%,
1.5%, 2.5%, 4%, and
custom
Precision of the pressure sensor.
Transferfunction
Linear, square root,
square
Type of transfer function of the pressure sensor
Owner
Letter, numeral, symbol
Owner of the pressure sensor
Location
Letter, numeral, symbol
Location of the pressure sensor
Notes
Letter, numeral, symbol
Notes of the pressure sensor
Table 5- 5 Task mode pressure transducer information
3. Task setting
For the contents, refer to Section 5.2.1 Task setting for calibration of the analog pressure gauge.
4. Task start
 For some contents, refer to Section 5.2.1 Task start for calibration of the analog pressure gauge.
Note that it does not require a manual input of the indicated value in this test.
