107
Notes
Letter, numeral, symbol
Notes of the contact pressure gauge
Table 5- 9 Task mode contact pressure gauge information
3. Task setting
Select the task in the task list to enter the instrument parameter interface, click the start icon to enter
the execution information interface, and input the calibration process information of the contact
pressure gauge in turn:
Item
Effective value
Description
Set point list
Effective value of the set
point pressure depends on
calibrated gauge
Pressure range; up to 17
calibration points can be set
Set the calibration point for the task, and the calibrator
will automatically set the default calibration points
based on the range of the calibrated instrument and
the number of the calibration points. The value and
number of points can be adjusted as necessary.
Cycle number
1, 2, 3
Select the number of calibration process cycles
Stroke
Round trip and one way
Select the calibration task stroke mode
The number of
readings
Integer of 1 ~ 6
Input the number of readings to be taken when the
calibrator reaches the set point
Reading interval
Integer of (1 ~ 600)
seconds
Interval time between collection of two readings
