108
Dwell time
Integer of (1 ~ 600)
seconds
Waiting time from a stable set point an the collection of
all readings
Input format
Value, the number of scales
1. Value: Digital display of pressure value
2. The number of scales: The pressure value is
displayed by counting the number of scales to facilitate
the reading and comparison with the value indicated by
the pressure gauge. The calibrated reading = standard
value + deviation number of scales X minimum scale
division
Tapping
Enable, disable
When enabled, the value of the pressure gauge
needs to be inputed twice for each calibration point,
and then the calibrator will advamce to the next
calibration point to continue the task
Electric contact test
Open, close
Select whether to test the electric contacts
Electric contact test
point control
pressure rate
1~10000Pa/s
Input the control pressure rate for electric contact test
Table 5- 10 Task setting of contact pressure gauge
4. Task start
 For some contents, refer to Section 5.2.1 Task start for calibration of the analog pressure
