30
Figure 3- 6 Voltage measurement
3. Functional operation
 Zeroing: Zero the measurement to eliminate drift. The allowable zeroing range is 1%FS.
 Scaling: Converts the current/voltage signal into pressure signal for display.
Item
Effective value
Description
Transfer function
Linear, square root, square
Type of the conversion function of the
scaled value
