31
Input range
0%~100%
Percentage of the input range of
scaling
Unit
Depend on the electrical measurement
selected
Input unit of scaling
Output range
0%~100%
Percentage of the output range of
scaling
Unit
User-editable field.
Output unit of scaling
Resolution
1, 0.1, 0.01, 0.001
Resolution of scaling
Table 3- 2 Scaling parameters
 Filter: Provides a first order linear filter and a moving average filter. The moving average filter
also allows setting the extremum pair.
Item
Effective value
Description
Filter type
First-order filter and average filter
Select the filtering mode.
Coefficient
0.01~1
Applicable to the first-order filter.
Filter sampling number
Integer 1~100
Sampling number of the average filter,
correlated with the sampling time.
Filter sampling time
0~20sec
Sampling time of the average filter,
correlated with the sampling number.
Extremum pair number
Integer 0~10
Extremum pair number of the average filter
