Chapter 8. Power Loss Recovery
8-2 MX2800 User Manual 61200290L1-1
NON-REDUNDANT POWER MODE
In Non-Redundant Power Mode, the MX2800 houses only one
power supply card and only one power source is available. There
is no power failure protection. If a power supply card fails, then
the unit is down until the card is repaired or replaced. See Figure
8-1 for an illustration.
Figure 8-1. Non-Redundant Power Mode
MX2800
Power supplies are hot-swappable.
